I. Product Information

• Brand name: JJRC
• Model: C8811
• Material: PA + fiber.
• Color: Black/red.
• Specification: 22*18*10 CM.
• Body weight: 480g.
• Remote control weight: 140g.
• Light configuration: Front headlights.

II. Power and Control System Parameters

• Motor: 1806 brushless motor.
• Electronic speed controller/receiver: 35A 2S integrated control (splash-proof).
• Body battery: 7.4V 650mAh.
• Servo: 3-wire, 9g.
• Remote control battery: 2 "AA" batteries (not included).
• Charger: USB balance charger.
• Frequency: 2.4GHz (supports multiple vehicles competing on the same field).
• Remote control distance: <100 meters.
• Remote control category: Full proportional synchronous control system.
• Battery life: About 15 minutes.
• Charging time: About 120 minutes (USB balance charger).
• Measured speed: No-load speed is 45 km/h.

III. Structure and Component Features

• Ball bearings: The whole vehicle uses ball bearings.
• Metal components: Metal front arm code, metal central drive shaft, metal front and rear dog bones, metal differential.

IV. Functions and Characteristics

• Simulated control: The whole vehicle adopts a simulated structure to realize full proportional stepless speed change, high-speed forward driving, backward, left and right turning.
• Four-wheel drive and suspension: Four-wheel drive, front and rear hydraulic shock absorption, double wishbone independent suspension.
• Versatile applicable venues: Flat ground, grassland, sand, and dry mud.
• Electronic speed controller characteristics: 35A 2S integrated control (splash-proof).
• Servo parameters: 3-wire 9-gram servo.
• Battery parameters: 7.4V 650mAh lithium battery (T plug).
• Lighting configuration: Equipped with LED headlights.
• New function: New remote control panel function, which can adjust the rudder volume.
• Car shell characteristics: The car shell is made of high-toughness explosion-proof PVC.
• Other accessories: Equipped with a head-up wheel and simulated off-road tires (with strong grip).
• Remote control adjustment: The remote control panel uses knob-type steering fine-tuning knobs and rudder volume adjustment knobs for more accurate and delicate adjustment; the steering angle is larger, and the vehicle is more flexible in steering, providing a better experience; the plug connecting the electronic speed controller and the battery is a model-level T-shaped plug, making the current output more stable.

V. Accessories

• 1X RC Car
• 1X Battery
• 1X Remote Controller
• 1X USB Charging Cable
• 1X Instruction Manual
