I. Basic Information

1. Model No.: JJRC C8828-ZW (Brushed Version)
2. Name: JJRC C8828 1/14 Full Proportional 4WD Electric Korean-Style Rally Car
3. Color: Blue
4. Scale: 1/14
5. Dimensions: 34 × 17 × 13.5 cm
6. Weight (Car Only): 891 g
7. Top Speed: 30 km/h
8. Material: Durable plastic body with a metal drive shaft
9. Structure: 4WD system with front and rear independent suspension
10. Differential: Planetary plastic gear differential

The JJRC C8828 brushed RC car combines realistic styling with reliable 4WD performance, ideal for both beginners and hobby-level rally enthusiasts.

II. Power & Control System

1. Motor: RC390 high-performance brushed motor
2. ESC/Receiver: 2-in-1 waterproof brushed electronic speed controller and receiver
3. Servo: Independent 3-wire 19g servo (2.2kg torque)
4. Battery: 7.4V 1500mAh 18650 Li-ion battery
5. Charging Cable: USB 7.4V-1000mA charger
6. Charging Time: About 240 minutes
7. Running Time: Around 14–15 minutes
8. Remote Frequency: 2.4GHz full proportional system
9. Control Distance: ≥70 meters
10. Transmitter Battery: 2 × AA batteries (not included)

Protection Functions:

• Intelligent charging with overcharge and overcurrent protection
• Motor jam protection
• Overheat safety shutdown with automatic recovery
• Low-voltage cutoff (6.3–6.4V) to prevent battery damage

III. Functions & Features

1. The JJRC 1/14 rally car C8828 features a 2.4G full proportional throttle and steering control system, offering precise handling and smooth control.
2. 4WD structure with front/rear independent suspension for enhanced stability
3. High-grip off-road rally tires for superior traction on multiple terrains
4. Realistic rally-style body shell for authentic looks
5. Full ball bearing transmission system for efficient power delivery
6. Plastic gears, metal drive shaft, and spring shock absorbers for durability
7. Waterproof 2CH ESC/receiver unit for splash resistance
8. RTR (Ready to Run) – fully assembled and ready for action out of the box

The JJRC C8828 RC rally car delivers strong power, stable performance, and realistic handling, making it a perfect choice for off-road and on-road fun alike.

IV. Package Included

1. JJRC C8828 RC Car ×1
2. 2.4GHz Transmitter ×1
3. 7.4V Li-ion Battery ×1
4. USB Charging Cable ×1
5. User Manual (Chinese & English) ×1
6. Drift Tires ×4
